SKU: S236
The S236 series thermal monocular is a NEW product in 2022. It helps to reveal your surroundings and see targets over 1600 meters away with ease. Simple to use, low learning cost. A perfect companion for thermal imaging hunting or outdoor journey, whether in the darkness or your own backyard
S236 Thermal Monocular details
Items | IRtech-S236E | IRtech-S236 | IRtech-S236P |
Detector | |||
Detector type | VOx | ||
Pixels | 384×288 | 384×288 | 640×512 |
Array size | 12μm | ||
Image function | |||
FOV | 10.5°x7.9° | 7.5°x5.7° | 12.5°x10° |
Lens focal length | 25mm | 35mm | 35mm |
Magnification | 2.3x | 3.25x | 1.95x |
NETD | ＜25mk | ||
Frame rate | 50HZ | ||
Focus | Manual focus | ||
Digital zoom | 1.0~4.0X continuously | ||
Distance display | yes | ||
LRF | Distance range 10~1000m | ||
Storage | |||
Storage | Build-in，32GB | ||
photo | Take more than 10,000 pictures | ||
recording | support | ||
Power system | |||
Battery type | Lithium battery | ||
Battery working time | ＞6h | ||
External power supply | DC5V/2A（ Type-C interface） | ||
Environmental parameters | |||
Operating temperature | -20℃～ +50℃ | ||
Storage temperature | -40℃～ +70℃ | ||
Encapsulation | IP66 | ||
Drop test | 1 m | ||
Physical features | |||
Weight | ＜550g | ||
Dimension | ＜220x105x65mm | ||
Detection distance | |||
Human 1.8*0.5m | 1000m | 1400m | |
Car 2.3*2.3m | 1600m | 2200m | |
Recognition distance | |||
Human 1.8*0.5m | 500m | 700m | |
Car 2.3*2.3m | 800m | 1100m | |
The S236 series thermal monocular is a NEW product in 2022. It helps to reveal your surroundings and see targets over 1600 me
