SKU#: DN10004
Color: Black
Service：OEM/ODM
Warranty: 12 moths
Features:
* 640*480 or 384*288 resolution optional;
* Support wifi, built-in thermal video record and image capture
* HD 1280*960 monitor;
* Working time up to 7 hours or more ;
Thermal Scope DN10004 details
Item | 25-240 | 25-384 | |
Detector | Type | Uncooled FPA | |
Pixel | 240×180 | 384×288 | |
Spectral range | 17μm | ||
NETD | ≤60mk@25℃ | ||
Image | Focal length | 25mm | |
FOV | 9.4°*7.0°(±5%) | 15°*11.2°(±5%) | |
Frame rate | 50HZ | ||
Focus | Manual | ||
Display | Monitor | AMOLED（390*390） | |
Eyeshield rubber ring | Yes | ||
Operation | Brightness/gain | Automatic / Manual | |
Polarity transformation | Black hot / White hot | ||
Digital zoom | 1.0--4.0Xcontinuous zoom | ||
WIFI | Yes | ||
Storage | Built in | 32G | |
Type | Photography and video recording | ||
Power | Battery | Rechargeable | |
Working | ＞5 hours | ||
Physical | IP ratings | IP66 | |
Dimension | ＜250*60*60mm | ||
Weight | 700g | ||
